Types of Fire Hydrant Nozzles
The fire hydrants are a firefighting tool. There are various components of fire hydrants such as hydrants, hoses, valves, water supply sources, pumps, pipes, and nozzles. There are different types of nozzles available to attach at the end of the pipes for throwing the water efficiently on fire.
The various types of fire hydrant nozzles make fire hydrants beneficial to use in different fire scenarios. With the help of fire hydrant nozzles, the water falls accurately on the fire and suppresses it in less time. Therefore, using a variety of nozzles is helpful and mandatory in the process of firefighting.
The five different types of fire hydrant nozzles are explained below:
1- Smooth or Solid Bore
The smooth or solid bore is the most basic one among the five types of fire hydrant nozzles. It is basic in both function and design. This particular nozzle provides a solid stream of water.
The water comes out in the form of large droplets and a solid stream is capable of penetrating the fire, hence extinguishing it efficiently. It is available in two ways either as a tip or in a break-apart configuration.
2- Fixed or Single Gallonage
The fixed or single gallonage nozzle provides water flow at a predetermined pressure. The rate of pressure stays fixed and cannot be changed significantly. But when the pressure of the nozzle is changed, the flow either increases or decreases according to the changes made in pump discharge pressure.
Fixed or single gallonage can be regarded as the simplest form of combination or fog nozzle. They provide high-quality patterns even when the nozzle pressure is reduced to as low as 50 psi. These fixed orifices are available in three variations: a tip, break-apart configuration, or nozzles.
3- Selectable or Adjustable Gallonage
Gallonage means the rate of flow of fire extinguishing agents. The selectable or adjustable gallonage provides the benefit of changing pressure without cutting off the supply of water to the fire. The feature is contrary to the fixed or single gallonage. But the fixed or single gallonage and selectable or adjustable pressure nozzles have something in common: they both provide high-quality patterns of water flow even when the pressure is low. These are also available in three variations, nozzles, tips, and break- apart configurations.
4- Automatic or Constant Pressure
Automatic or constant pressure nozzles can be used in a wide range of flows for maintaining comparatively a constant pressure. The constant pressure is maintained by a mechanical mechanism, typically by using a spring.
The spring is present in the nozzle and adjusts automatically to increase or decrease the flow for maintaining the outlet pressure. As a result, an optimum stream performance is produced. To maintain a constant pressure and for producing the optimum stream performance, the automatic or constant nozzles reduce the flow when a reduced pressure is given to them. These are also available in nozzles, tips, or break- apart configuration.
5- Multi-purpose Nozzles
The smooth bore and fog nozzle is combined to make a multi-purpose nozzle. So, they have the features of both, they can reach and penetrate at maximum like the smooth bore and produce a fog stream like the fog nozzle. This nozzle has the versatile ability of large flow at reduced pressure.
Due to this ability multi-purpose nozzles are suitable for many applications, such as:
1- Interiors.
2- Exteriors.
3- High-rise attacks.
4- CAFS systems.
5- Foam applications.
6- Direct and indirect attacks.
7- Cooling.
8- Protection.
9- Ventilation.
Normally it is available only as a nozzle.
Check Out These:
- Fire Retardant Chemical for Fabric
- Fire risk assessment for commercial property
- Fire Extinguishers in Pakistan
The purpose for Different types of Fire Hydrant Nozzles
Fire hydrant nozzles are important firefighting equipment. The nozzles are connected to the pipes or hoses through which the water flows to extinguish the fire. Nozzles help in getting the right amount of water, at the right angles and directions, and in the right places. There are the following purposes for using different types of fire hydrant nozzles:
1- To get a required flow of water
There is an orifice in the outlet of the nozzle. The size of the orifice provides a controlled and accurate flow of water.
2- Provide Reach and Penetration
The water flows through the nozzles, these nozzles change the water pressure into the velocity. Due to this velocity, water can reach the fire spot. The water must reach the fire to extinguish it.
3- Provide Shape
The nozzles create shapes for the water and provide patterns. A straight stream created by the nozzle can penetrate accurately, and a fog spray in the radiant heat protection.
Therefore, choosing the right type of fire hydrant nozzles ensures the correct flow of water and instant extinguishing of fire.
Conclusion
The fire hydrants are firefighting systems. They have fire hoses or pipes as a component. Nozzles are connected at the end of the fire hoses. The purpose of nozzles is to provide control over water flow, generate precise water pressure, to get the reach by creating shape for extinguishing the fire. There are different types of fire hydrants nozzles for optimum performance. You can choose the right type according to your needs.
